ADV 180cc
$1,350.00
Price drop reminder
- SKU： ADV 180cc
- Product Code: ADV 180cc
- Availability: 1000
If the price of the product is reduced within 30 days, we will notify you via email, SMS and mobile client~
If the goods arrive within 30 days, we will notify you via email, SMS and mobile client~
| Model： | ADV 180 | |
| Dimension.(L×W×H)(mm) | 1960X730X1170 | |
| Wheel base(mm) | 1330 | |
| Ground clearance (mm) | 170 | |
| Seat height(mm) | 780 | |
| Turning angle | ＜48° | |
| Min turning radius(mm) | 2040 | |
| Front/rear sprocket teeth | belt transmission | |
| Gearshift | automatic | |
| Fuel tank(L) | 12L | |
| Fuel Type | Gasoline | |
| Max. Load Capacity(kg) | 150 | |
| Dead Weight(kg) | 150 | |
| Displacement/Power(ml/kw): | 180CC | |
| Eco fuel consumption(L/100km) | 3 | |
| Brake Mode： | Front Wheel | Discbrake |
| Rear Wheel | Drum brake | |
| Front Wheel | Manual | |
| Brake Operation Mode | Rear Wheel | kick |
| Wheel Rim Type | Front aluminum wheel: 2.50-14 | |
| Rear aluminum wheel: 2.50-13 | ||
| Tire type | With tube | |
| Front tire | 110/80-14 | |
| Rear tire | 130/70-13 | |
| Head light | 12V 35W/35W | |
| Winker | 12V 10W | |
| Battery（mm） | Jelly battery 12N8.6AH 150×60×130 | |
| Engine type | 1-Cylinder, 4-stroke, water-cool, EFI | |
| Engine Model | K29 | |
| Start | Electric | |
| Ignition | CDI | |
| Bore×Distance | 63x57.9 | |
| Displacement(ml) | 180 | |
| Compression rate | 9.5:1 | |
| Magneto | 12V 8head full phase | |
| Oil capacity(ml) | 1100 | |
| Spark plug | D8TC | |
| Spark clearance(mm) | 0.6~0.7 | |
| Valve clearance(mm) | 0.04~0.06 | |
| Lubriation | Press+splash | |
| Carburetor | Valcuum | |
| Transmission | CVT belt | |
| Clutch type | automatic | |
| N.W.(kg) | 35 | |
| Max power | 10.4KW(7500r/min±5%) | |
| Max torque | 14.7N·m(6000r/min) | |
| Load Quantity | 40HQ | 130 CKD |
| Load Quantity | 40HQ | 84 SKD |
