Broz

Broz

Broz

  • Brand:Chongqing
  • Product Code: Broz
  • Reward Points: 300
  • Availability: In Stock
  • $550.00

  • Ex Tax: $550.00
  • Price in reward points: 400

Available Options

Dimension.(L×W×H)(mm) 2080×840×1180
Wheel base(mm) 1360
Ground (mm) 265
Seat height(mm) 860
Turning angle 48 degree
Min turning radius(mm) 2120
Front/rear sprocket teeth 17/50
Gearshift 5-forward
Fuel tank(L) 9L
 Fuel Type Gasoline
Max. Load Capacity(kg) 150
Dead Weight(kg) 121
Displacement/Power(ml/kw): 197cc
Eco fuel consumption(L/100km) 2.2L
Brake Mode Front Wheel Disc brake
Rear Wheel Drum brake
  Front Wheel Manual
Brake Operation Mode Rear Wheel kick
Wheel Rim Type Front spoke wheel:        2.15*17
Rear spoke wheel:        2.15*17
Tire type With tube
Front tire 80/100-19
Rear tire 110/100-18
Head light 12V  35W/35W
Winker 12V  10W
Batterymm With acid: 12V7A
Engine type 1-Cylinder, 4-stroke, air-cool, OHC
Engine Model 161FMJ
Start Electric+kick
Ignition CDI
Bore×Distance 61×49.5
Displacement(ml) 144.6
Compression rate 8.6:1
Magneto 12V 8head full phase
Oil capacity(ml) 1100
Spark plug D8TC
Spark clearance(mm) 0.6~0.7
Valve clearance(mm) 0.04~0.06
Lubriation Press+splash
Carburetor PZ27
Transmission Constant mesh
Clutch type manual, wet, multi-disc
Initial trans rate 3.333
Gearshift rates 1st: 2.769 ,2nd: 1.882,third; 1.400,forth: 1.130,fifth: 0.960
Final trans Chain
Rotation direction Facing shaft, unclock wise
Size(mm) 358×324×446
N.W.(kg) 31
Rated power 8.5KW(8500r/min±5%)
Max power 9.6KW(9500r/min±5%)
Max torque 9.5N·m(7500r/min)
